APPENDIX E - MODBUS REGISTER MAP
Absolute Register Address Description Range Units
30143/40143 Rated RMS Voltage
0: 100
1: 110
2: 120
3: 200
4: 208
5: 220
6: 230
7: 240
8: 350
9: 380
10: 400
11: 415
12: 440
13: 460
14: 480
15: 500
16: 525
17: 575
18: 600
19: 660
20: 690
21: 800
22: 1000
23: 1140
Vrms
30144/40144 Input Phase Sensitivity
0: Ins
1: ABC
2: CBA
3: SPH
-
30145/40145 Motor Rated Power Factor 1 – 100 -
30146/40146 Overcurrent Enable
0: Disabled
1: Enabled
-
30147/40147 Overcurrent Level 50 – 800 % FLA
30148/40148 Overcurrent Delay Time Enable
0: Disabled
1: Enabled
-
30149/40149 Overcurrent Delay Time 1 – 900 100 mSec
30150/40150 Undercurrent Trip Enable
0: Disabled
1: Enabled
-
30151/40151 Undercurrent Trip Level 5 – 100 % FLA
30152/40152 Undercurrent Trip Delay Time Enable
0: Disabled
1: Enabled
-
30153/40153 Undercurrent Trip Delay Time 1 – 900 100 mSec
30154/40154 Current Imbalance Trip Enable
0: Disabled
1: Enabled
-
30155/40155 Current Imbalance Trip Level 5 – 40 %
30156/40156 Residual Ground Fault Trip Enable
0: Disabled
1: Enabled
-
30157/40157 Residual Ground Fault Trip Level 5 – 100 % FLA
30158/40158 Over Voltage Trip Enable
0: Disabled
1: Enabled
-
30159/40159 Over Voltage Trip Level 1 – 40 %
30160/40160 Under Voltage Trip Enable
0: Disabled
1: Enabled
-
30161/40161 Under Voltage Trip Level 1 – 40 %
30162/40162 Over/Under Voltage Delay Time 1 – 900 100 mSec
30163/40163 Digital Input Trip Delay Time 1 – 900 100 mSec
30164/40164 Auto Fault Reset Enable
0: Disabled
1: Enabled
-
30165/40165 Auto Fault Reset Delay Time 1 – 900 Sec
30166/40166 Auto Fault Reset Count Enable
0: Disabled
1: Enabled
-
30167/40167 Auto Fault Reset Count 1 – 10 -
