Chapter 6 - Parameter Description [AFN]
6-36
AFN-80: Power On Display
This parameter selects which parameter will be
displayed first on the keypad when the power is turned
on.
Setting
Range
Description
0 DRV-00 [Command Frequency]
1 DRV-10 [Output Current]
2 DRV-11 [DC Link Voltage]
3 DRV-12 [Power], Select with AFN-81
4 DRV-15 [Target/Output]
5 DRV-16 [Ref/Fdbk] when in PI Mode
6 DRV-18 [PI Parameters] when in PI Mode
7 DRV-20 [Ext-PID]
8 DRV-24 [Output Currents]
9 FUN-54 [KiloWattHour]
10 FUN-55 [Inverter Temperature]
11 AFN-84 [On Time]
12 AFN-85 [Run Time]
AFN-81: User display selection
Related Function: DRV-12 [User display selection]
This parameter selects what function is to be displayed
in DRV-12.
AFN-81
Setting Range
Name Description
Voltage
Output
voltage
Display the output voltage
of the drive (Factory
setting)
Watt
Output
power
Display the output power
of the drive
AFN-82: Software Version
This parameter displays the software version. This will
vary depending on software version installed in the
drive. Version 1.0 and later applies to new control
board.
AFN-83, 84, 85: Last Trip Time, On-time, Run-time
Displays time elapsed after the last trip occurs.
Note: Time is reset automatically after each trip.
This parameter displays the total time that the drive has
had input power applied.
This parameter displays the total time that the drive has
been operating. Pre-heat time is included in this
reading.
FUN-83~85 display X : XX : XX : XX : XX
(Year:Month:Day:Hour:Minute)
AFN
►
PowerOn disp
80 0
Factory Default: 0
AFN
►
S/W Version
82 Ver 1.0
Factory Default: Ver. 1.0
AFN
►
User Disp
81 Voltage
Factory Default: Voltage
AFN
►
LastTripTime
83 0:00:00:00:00
Factory Default: 0:00:00:00:00
AFN
►
On-time
84 0:00:00:00:00
Factory Default: 0:00:00:00:00
AFN
►
Run-time
85 0:00:00:00:00
Factory Default: 0:00:00:00:00
