Appendix
106
2022-05 EN 50400685.00A.04
Fault Solution
Knife defective
> Replace the knife.
Machine not running
> Connect machine to the power source and switch it on.
> Close the looper cover.
10.4 Technical Specifications
Name Value Unit
Number of stitches 31
Number of loopers 3
Number of needles 1− 5
Needle system ELx705
Needle size 80 − 100 (12 − 16)
Differential feed 0.6 − 2.0
Maximum fabric thickness 5 (0,23) mm (in)
Cutting width overlock LN 5.0 − 7.0 (0.19 − 0.27) mm (in)
Cutting width overlock RN 3.0 − 5.0 (0.12 − 0.19) mm (in)
Stitch width coverstitches 2.8 − 5.6 (0.11 − 0.22) mm (in)
Stitch width combostitches 7.8 − 12.6 (0.31 − 0.49) mm (in)
Maximum sewing speed 1300 Stitches per minute
Dimensions without retractable thread guide (LxWxH) 43 x 27 x 29 (16.92 x 10.62 x
11.41)
cm (in)
Dimensions with slide-on table / cut-offs bin (LxWxH) 59 x 40 x 29 (23.22 x 15.78 x
11.41)
cm (in)
Weight of the machine 8.9 (19.6) kg (lb)
Weight packaged 12.8 (28.2) kg (lb)
Input voltage (energy consumption) 120 (80) / 230 − 240 (75) V (W)
Protection class (Electrical Engineering) II
Date of manufacture Visible on the type plate
