Bernette b68 AIRLOCK - Stitch Chart and Settings

Selecting a Stitch
49
2022-05 EN 50400685.00A.04
5.2 Stitch Chart
This manual includes a stitch overview with all necessary default settings for each stitch. These default values
may vary depending on the used material.
> Remove all the needles which are not required.
> Set the mtc micro thread control to center position.
No. Stitch Name Stitch Pattern
No.1 4-Thread Overlock with
Integrated Safety Seam
4 4 4 4 ─ 6 N 2.5 1
No.2 3-Thread Super Stretch 5 4 4 ─ 6 N 2.5 1
No.3 3-Thread Overlock Wide (LN) 4 ─ 4 4 ─ 6 N 2.5 1
No.4 3-Thread Overlock Narrow (RN) ─ 4.5 4 4 ─ 6 N 2.5 1
No.5 3-Thread Flatlock Wide (LN) 0 ─ 5 8 ─ 6.5 N 2.5 1
No.6 3-Thread Flatlock Narrow (RN) ─ 0 6.5 8 ─ 5.5 N 2.5 1
No.7 3-Thread Rolled Seam ─ 4.5 5 4 ─ 6 R 1.5 1
No.8 3-Thread Rolled Hem ─ 4.5 5 7 ─ 5 R 1.5 1
