Threading
69
2022-05 EN 50400685.00A.04
Threading the Center Coverstitch Needle Thread CC/Green
The center coverstitch needle thread is marked in green all along the thread path.
Exception:
For a combostitch with chainstitch, the yellow thread path must be followed for the center coverstitch needle
thread.
Prerequisite:
• «Threading is prepared».
> Pull the thread beneath the thread guide plate to the back left through the center opening of the thread
deflection finger.
> Place the thread along the colored marking, then over the needle thread take-up cover and pull it
towards the needle.
> Hook the thread into the second thread guide from left of the needle holder.
> Thread the needle eye.
> Place the thread beneath the presser foot to the back left.
> When all needed threads are threaded, lower the presser foot.
