Figure Name Purpose
Retractable Thread Guide For an even unwinding of the thread from the
thread cones.
Accessories Box To store the supplied accessories as well as
optional accessories.
Accessories behind the Threader Cover
The most often used accessories while sewing are stored behind the threader cover on the machine, so it is
always quickly at hand.
Figure Name Purpose
Needle Set ELx705 CF Recommended needles for all-purpose use.
Screwdriver To loosen or tighten the fixing screws on the
needle holder.
Upper Looper Cover To cover the upper looper.
For sewing 2-thread overlock and the 3-thread
super stretch stitch.
Brush To clean the feed dog and the looper area.
Tweezers For gripping the thread in tight positions.
Needle Threader/
Inserter
To manually thread, insert and remove the needle.
