Setting Up the Machine
34
2022-05 EN 50400685.00A.04
Attaching/Removing the Knee Llifter
Temporarily lifting the presser foot using the knee lifter allows to position the sewing project with both
hands.
> To attach the knee lifter, push the knee lifter engaging cam in a horizontal position into the knee lifter
connection until it stops.
> To remove the knee lifter, pull the knee lifter out of the knee lifter connection without swinging the knee
lifter sideways.
The swing-out position of the knee lifter can be adjusted at an authorized bernette dealer if required.
Attaching/Removing the Cut-offs Bin
The cut-offs bin catches the fabric scraps during the sewing process.
> To attach the cut-offs bin, hook the cut-offs bin into the snap-in opening on the looper cover.
> To remove the cut-offs bin, lift the cut-offs bin out of the snap-in opening on the looper cover.
