Bernette b68 AIRLOCK - Needle Area and Threading

Setting Up the Machine
30
2022-05 EN 50400685.00A.04
> Lift the presser foot spring slightly and remove the presser foot.
> Lift the presser foot spring slightly and place the new presser foot beneath the shaft groove so that the
shaft groove lies exactly above the presser foot pin.
> Lower the presser foot shaft carefully until the shaft groove engages with the presser foot pin.
> Raise the presser foot.
3.8 Needle Area
Needle Holder
The needle holder can hold five needles. The machine is designed for needles of the ELx705 system. Needle
sizes between 80-100 (12-16) are to be used for this machine.
LN
RN
L
C
CC
RC
Needles for Coverstitches
«LC» Left coverstitch nedle for coverstitches and chainstitches.
«CC» Center cverstitch nedle for coverstitches and chainstitches.
«RC» Right cverstitch nedle for coverstitches.
Needles for Overlock Stitches
«LN» Left nedle for overlock stitches.
«RN» Right nedle for overlock stitches.
Changing the Needle
The use of the needle inserter is recommended and prevents the needle from falling into the feed dog area.
Correctly inserted needles are not at the same height.
The needle holder screws must always be tightened, even if no needles are inserted. This prevents the needle
holding screws from falling out because of vibrations.
