Setting Up the Machine
28
2022-05 EN 50400685.00A.04
Place the Spool Disc
The spool disc ensures the stability of the thread spool and the even unwinding of the thread.
> Place the thread spool on the spool holder.
> Push the flat side of the spool cap over the spool pin to the thread spool.
Using the Spool Net
The spool net prevents the thread from sliding down from the thread spool and is recommended for special
threads.
• Thin threads, which slide easily off the spool
• Nylon, rayon, silk threads or effect and metallic threads
> Put the spool net over the thread spool from above and pull the thread end upwards.
3.7 Presser Foot
Positioning the Presser Foot Up/Down
The lifted presser foot allows you to place the sewing project under the presser foot. The lowered presser
foot is a prerequisite for starting to sew.
> Lift the presser foot lifter until it engages.
– The presser foot remains in the upper position.
– The thread tension is released.
