Bernette b77 - 1.3 Overview User Interface

My bernette
18
2022-08 EN 5020077.40A.04
1.3 Overview User Interface
Overview Functions/Visual Information
1
2
3
4
5
1 Upper Thread Tension 4 Foot Pressure
2 Needle Selection 5 Stitch Plate Selection
3 Presser Foot Display/Presser Foot Selection
Overview Functions and Views
Illustration Name Purpose
Close The display is closed and the
previously made adjustments are
saved.

«Plus» / «Minus» Change setting values.
Confirm Confirms the previously adjusted
alterations. The display is closed.
Cancel The process is canceled. The
display is closed and the
previously made adjustments are
not saved.
Slide By moving the slide the setting
values are changed.
Switch Activates or deactivates
functions.
USB Storage Space The percentage of used USB
storage (%) will be displayed in
the green bar icon.
