Bernette b77 - Page 40

Sewing Preparation
40
2022-08 EN 5020077.40A.04
> Pull the end of the thread through one of the inner holes on the bobbin and place the empty bobbin on
the bobbin winding unit.
1
2
> Push the bobbin to the rigth-hand position.
– The button «Start/Stop» flashes and the display for winding appears.
> Hold the end of the thread tightly with one hand.
> To start the winding process for a few rotations and then stop, push the button «Start/Stop», so that the
thread is held tight on the bobbin.
> Cut the end of the thread above the inner hole.
> To continue the winding process, push the button «Start/Stop».
> To stop the winding process, push the button «Start/Stopp».
> Push the bobbin winding unit to the left into the starting position.
> Remove the bobbin and cut the thread.
