46
1
2
3
5
4
Replacing the Light Bulb
WARNINGS:
Turn off the power before replacing the light bulb.
The bulb could be HOT, wait until it has cooled down
before touching it.
Toremove:
Remove the cap and setscrew. Remove the faceplate.
Pull out the bulb from the socket.
Toreplace:
Insert the bulb into the opening of the socket.
Attach the faceplate with the setscrew, and attach the
cap.
1 Cap
2 Setscrew
3 Faceplate
4 Lamp Socket
5 Light bulb
