Bernina deco 330 - Changing External Parts (6) Front Cover

6
Deco 330
Toremove:
1Removetheface cover,beltcover,basecover and bed
cover. (See page 1 - 4).
2RemoveScrew(A) andremovetheArmthread
guide (lower) .
3Remove Screw (B) .
4LoosenScrews (C) , (D) .
5Disconnecteachconnectorandremovethefrontcover.
Note: UnlocktheHooksbefore removing the Front cover.
Screw(A)
Armthreadguide(Lower)
Screw(B)
Screw(C)
Screw(D)
Hooks (4 spots)
Toattach:
6 Followtheaboveprocedureinreverse.
Note: See page 21 (Diagram) for “Connectors
Connection”.
Changing External Parts (6) Front Cover
Front cover
1
2
2
1
4
3
6
5
2
1
4
3
6
5
3
4
5
