Deco 330
Adjusting X and Y Sensors
To adjust X and Ysensors:
1 Turnthepower switch “ON” (The carriage is
automatically set at starting position.)
2 Turnthepower switch “OFF” and then removethe
base unit.
3 Loosen ScrewA andmovetheY-Sensor xing
plate to adjust the carriage position.
Turnthepower switch “ON” again to checkifthe
Distance (Y) 2 is adjusted to 2.5 mm.
Tighten Screw(A)
1
.
4LoosenscrewB
4
and movetheX-shieldplate
to adjust the carriage position (X-1)
5
and
(X-2)
6
.
Turnthepower switch “ON” again to checkifthe
distance (X-1)
5
is adjusted to 69.5 mm and
(X-2)
6
is adjusted to 2.5 mm.
5TightenScrew
4
.
6. Attach the base.
1
2
3
4
5
7
6
1
3
7
Screw (A)
Y(2.5mm)
YSensorxingplate
Screw (B)
X-1 (69.5 mm)
X-2 (2.5 mm) between the edge of carriage
and Base
Xshieldplate
1
6
7
2
4
5
3
