Deco 330
Adjusting Height of EmbroideryFootP
Space between the needle plate and the bottom surface of the Foot (P) should be
1.0 to 1.6 mm, when the needle bar is at its lowest position.
1Removethefrontcover unit. (See page 6)
2Lower the needle bar and lower the presser foot lifter.
3Insertthe1.2mmThickness gauge
1
between
the Embroidery Foot (P)
2
and the needle plate.
4WhilepressingthePressurebaractuator3down
against the upper shaft cam, loosen the Screw (A)
4
and push it down to the direction of arrow,thentighten
Screw(A)
4
again.
5Reattachtherearcover.
1
Thickness gauge
2
Embroidery foot (P)
3
Pressure bar actuator
Screw(A)
Needle
Needle plate
3
4
2
1
5
6
5
4
6
