Bernina deco 330 - Replacing Carriage Plate (Unit)

25
Deco 330
Replacing CarriagePlate(Unit)
Toremove:
1 Turn the power switch “ON” and select the pattern No.1.
2 Turnthepower switch “OFF” and removetheCover
cap
1
.(Unlockthehookfromtheinside.)
3 Turnthepower switch “ON” to returnthecarriage to
the home position.
4RemoveScrews
4
(3 pieces) and removethe
carriage plate.
Toattach:
5Attachthecarriage plate (unit) and tighten screws
temporarily.
6Adjustthecarriage plate position so that its top surface
is parallel and the same level with the bed surface.
Tighten the screws securely.
7Attachthecover cap
1
.
1
2
3
4
4
5
Cover cap
Hook
Drop plate
Screws
Armsurface
