Bernina deco 330 - Replacing Printed Circuit Board

20
Deco 330
Replacing Printed Circuit BoardA
Toremove:
1Removethefrontcover. (See page 6)
2Pullouttheconnectorsofprinted circuit board F
LCD Harness,Inverter and Touch panel.
3RemoveScrews (5 pieces)
1
and the Printed
circuit board A
2
with the Card guide
3
.
Toattach:
4 Followtheaboveprocedureinreverse.
1
1
2
1
3
1
Screws (5 pieces)
Printed circuit board (A)
Card guide
1
2
3
