Deco 330
Changing External Parts (2) Belt Cover
Replacing the belt cover
Toremove:
1. RemovetheCap andScrew(A) .
2. Loosen Screw(B) .
3. Lay the machine down on its back and remove ScrewsC
and D , then remove the Belt cover .
Cap
Screw (A)
Screw (B)
Screw(C)
Screw(D)
Belt cover
Toattach:
4. Attach the Belt Cover with Screws (A - D) - .
5. Attach the Cap .
