Bernina deco 330 - Replacing Threader Plate and Adjustment

17
Deco 330
Replacing Threader Plate and Adjustment
If the hook on the threader plate is damaged, replace it asfollows.
1
2
3
View-X
(X)
Fig. 1
Fig.2
Fig.3
3
1
2
4
5
2
1
4
3
5
Toreplace:
1PryouttheThreaderplateholder 1 withscrewdriver
while pushing and holding the Threader knob 4 (See
g.1.).
2AlignthegrooveonthenewThreaderplateholder 1
with the Pin
2
on the threader shaft. Push the
Threader plate holder
1
up until it snaps in place.
Threader plate holder
Pin
Hook
Threader knob
Adjustment procedure:
1. If the threader hook thrusts or hits against either left
or right edge of the needle eye: Loosen Screw(A) 1
and adjust the position of the Threader plate
2
.
(See g. 2).
2. If the threader hook thrusts against either top or
bottom edge of the needle eye,ormissestheneedle
eye:
Removetheface cover and loosen Screw(B)
3
.
Move the Threader position adjusting holder 4 up or
down to adjust the hook position.
Screw (A)
Threader plate
Screw (B)
Threader position adjusting holder
Needle bar
4
2
1
3
4
