Bernina deco 330 - Adjusting Clearance between Needle and Hook

11
Deco 330
Adjusting Clearance between Needle and Hook
The clearance between needle and rotaryhookshouldbe-0.10to+0.05mm.
1Removetheneedleplate,bobbinholder,basecover
and bed cover (See page 3 - 4).
Replace the needle with the Test pin
5
.
2LoosenScrews (A)
1
,(B)
4
,(C) 2 andtighten
Screw(C) temporarily.
3 Turnthehandwheeltobring the tip of the rotary
hook behind the test pin.
Adjust the clearance between the Test pin and the
Tip of rotaryhook
7
to - 0.10 to + 0.05 mm
6
by
moving the Rotaryhooksetplate
3
up or down.
4TightentheScrews (A) 1 ,(B)
4
,(C)
2
rmly.
5Checktherotaryhookdriver gear and the lower shaft
gear backlash.
If gears mesh or engage tightly or loosely,check
“Adjusting Backlash between Hook DriveGearand
Lower Shaft Gear”. (See page 12 )
6Reattachthebedcover,basecover,baselid,bobbin
holder,needleplateandneedle.
Screw(A)
Screw(C)
Rotaryhooksetplate
Screw(B)
Test pin
-0.10to+0.05mm
Tip of rotary hook
2
1
3
4
6
5
7
2
3
4
6
5
7
2
5
1
