Beta EVO 2T User Manual

2
OPERATION
21
GB
1
CLUTCH LEVER
Clutch lever 1 is fitted to the left-hand side
of the handlebars. Screw A can be used
to alter the home position of the lever (see
Adjustments).
LH SWITCH
The off switch is positioned on the left-hand
side of the handlebar and consists of the
following:
shutdowns engine : it is necessary to
hold it until the engine stops.
RH SWITCH
The lights and services switch is located
on the right-hand side of the radiator and
consists of the following:
1 Rear light power on/off
2 Mapping change switch
By acting on the switch shown in the figure,
it is possible to select one of two possible
mappings for the ignition advance.
With the switch in position , “soft” map-
ping more suited to muddy terrain and for
a gentler response of the bike is selected.
With the switch in position “hard”
mapping that is more suitable for dry land
and for a more aggressive response of the
bike is selected.
A
2
1

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
