4
CHECKS AND MAINTENANCE
44
GB
2 mm
FRONT BRAKE LINING CONTROL
In order to verify the wear condition of front
brake is enough to view the caliper from
the bottom, where is possible to glimpse
the brake lining tails which will have to
show a brake of 2 mm in thickness. If the
stratum is lesser let’s start replacing them.
NOTE:
Perform the check according to the times
shown in the table on page 61.
To replace, contact authorised Betamotor
customer service.
2
1
A
REAR BRAKE
CHECK THE LEVEL OF THE REAR
BRAKE FLUID
Check the level of the brake fluid through
sight A. The level of the fluid should never
fall below the mark in the sight.
RESTORING THE LEVEL OF THE
REAR BRAKE FLUID
To restore the level of the brake fluid, loosen
the two screws 1, lift cap 2 and add brake
fluid until its level is 5 mm below the upper
rim of the reservoir.
Use the liquid indicated on page 18 in
the “Recommended lubricants and liquids”
table.
