Beta EVO 2T User Manual

2
OPERATION
22
GB
1
FRONT BRAKE LEVER AND GAS
CONTROL
The front brake lever 1 and the gas throt-
tle 2 are located on the right side of the
handlebar.
GEARCHANGE LEVER
Gearchange lever is fitted to the left side
of the engine.
The positions corresponding to the different
gears are shown in the figure.
2
1
2
3
4
5
N
6
BRAKE PEDAL
Brake pedal is located in front of the right-
hand footrest.
KICK-START
The kick-start pedal is located on the left
side of the engine. The upper part is rotat-
able.

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
