Beta EVO 2T User Manual

4
CHECKS AND MAINTENANCE
58
GB
REAR TAIL LIGHT
Keep the tail light glass clean at all times
(see page 59).
Remove the screws indicated in the figure.
Remove the bulb holder from its place.
Remove the bulb.
To reassemble, proceed inversely as de-
scribed above.
0,5Nm

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
