Beta EVO 2T User Manual

4
CHECKS AND MAINTENANCE
57
GB
HEADLIGHT
Keep the headlight glass clean at all times
(page 59).
REPLACING THE HEADLIGHT
BULBS
Dismantle the headlight mask removing
the two retaining screws 1 indicated in
the figure.
Remove the screws 2 indicated in the
figure.
Take out the bulb assembly from the bulb
holder.
Remove the bulb from the connectors and
carry out replacement.
To reassemble, proceed inversely as de-
scribed above.
1
2
1Nm
0,5Nm

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
