Beta EVO 2T User Manual

4
CHECKS AND MAINTENANCE
50
GB
OIL FORK
The procedure for changing the oil in the
forks is provided only for information.
We recommend having the operation
performed by a BETAMOTOR authorized
workshop.
REMOVING LEGS
To replace, proceed as follows:
Position the vehicle on the central bike
stand.
Remove the front wheel.
Remove the mudguard, the brake caliper
and brake disc cover.
Loosen the screws 1 and pull off the stems.
OIL REPLACEMENT RIGHT LEG
Unscrew upper plug 2.
Unscrew fixing lock nut and take off the
plug.
Unscrew the fixing screw of the cartridge
positioned under the fork leg, and extract
the cartridge.
1
2

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
