Beta EVO 2T User Manual

3
ADJUSTMENTS
29
GB
ADJUSTMENT OF GAS
CLEARANCE
The throttle control cable should always
have a 3-5 mm play. In addition, the idle
speed should not change when the han-
dlebars are fully rotated to the left or right.
To adjust the clearance proceed as follows:
- Loosen ring 1.
- Rotate register 2 with respect to sheath 3.
- Tighten ring 1.
2
1
3
CLUTCH
The position of the lever is controlled
through the use of register 1.
Once the position of the lever has been
changed, register 2 must be changed to
restore the initial correct clearance.
The idle stroke of push rod must not be less
than 0.9 mm
ATTENTION: reduced clearance
leads to premature wear of the discs
and overheating of the entire clutch
group.
0,9 mm
2
1

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
