Beta EVO 2T User Manual

4
CHECKS AND MAINTENANCE
38
GB
CLEANING AIR FILTER
- Thoroughly wash the filter with water and
soap.
- Dry the filter.
- Wet the filter with specific oil and then
remove the excess oil to prevent it from
dripping.
- If necessary also clean the interior of the
filter box.
WARNING:
Do not clean the filter with gasoline
or petrol.
NOTE:
If the filter is damaged, replace it
immediately.
2
- Remove the filter frame and the filter by
unscrewing the screw 2.
WARNING:
After every intervention, check that
nothing has been left inside the filter
box.
- Reassemble by performing the operations
in reverse order.

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
