TIGHTENING TORQUE OVERVIEW
Here below is an overview of the tightening torque of all pieces subject to adjust-
ment or maintenance:
Forecarriage
Tightening torque [Nm] Threadlock
Wheel pin
50
Fork foots - wheel pin
10*
Brake caliper - Fork
25 M
Steering head base - fork legs
10*
Steering head - fork legs
10
Stem pin on steering head
10
Upper handlebar u-bolt 20
Rear axle
Tightening torque [Nm] Threadlock
Wheel pin
80
Rear shock absorber - frame
45
Rear shock absorber - rocker arm
45
Connecting rod - frame
30
Connecting rod - rocker arm
45
Rocker arm - swinging arm
45
Engine
Tightening torque [Nm] Threadlock
Gearbox oil drain plug 10
Bleeding screw cooling system 10
Superstructures
Tightening torque [Nm] Grease
Front mudguard 10
Rear mudguard 2,5 G
