Beta EVO 2T - Legs Assembly and Parts

4
CHECKS AND MAINTENANCE
52
GB
LEGS ASSEMBLY AND PARTS
Apply the legs to the vehicle and tighten
the screws 1 to the torque indicated.
ATTENTION: Tightening of the screws
should be carried out by adjusting the
torque wrench to to the stability torque with
repeated tightening until stability torque has
been achieved.
Grease the wheel bolt.
Apply wheel and wheel bolt.
Apply brake caliper, disc cover and fender.
Tighten to the torque indicated.
ATTENTION: Tightening of the
screws should be carried out by
adjusting the torque wrench to to
the stability torque with repeated
tightening until stability torque has
been achieved.
Place the vehicle on the ground.
Compress and release the fork 3-4 times.
Tighten the wheel bolt and the screws of
the foot.
ATTENTION: Tightening of the
screws should be carried out by
adjusting the torque wrench to to
the stability torque with repeated
tightening until stability torque has
been achieved.
1
10Nm
10Nm
10Nm
25Nm
50Nm
