Beta EVO 2T User Manual

4
CHECKS AND MAINTENANCE
40
GB
1
CARBURETOR
DRAINING THE CARBURETOR
FLOAT CHAMBER
If the carburetor tank needs to be emptied,
proceed as described. Perform the opera-
tion once the engine is cold.
Turn the fuel cock to OFF position (see
page 20).
Place a cloth under the carburettor in order
to collect the fuel that comes out.
Loosen screw 1 and drain the fuel until
complete emptying of the tank.
Tighten screw 1.
WARNING:
Follow action on a cold engine.
WARNING:
Fire hazard. Fuel is highly flam-
mable.
Always stop the engine when
refuelling and keep open
flames and lighted cigarettes
away.
Refuel in an open well ventilated area.
Immediately clean up any spilled
fuel.
WARNING:
Risk of poisoning!
Fuel is poisonous liquid and a health
hazard.
Wear appropriate protective cloth-
ing and protection gloves.

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
