ADJUSTMENTS
31
GB
SHOCK ABSORBER
ADJUSTING THE REBOUND
DAMPER
The hydraulic brake unit in extension deter-
mines the behaviour in the extension phase
of the shock absorber and can be adjusted
using screw 1. Turning clockwise increases
the action of the brake in extension, while
rotating counter-clockwise decreases the
action of the brake in extension.
For standard calibration, refer to page
11 .
NOTE:
for adjustment use a T-handle wrenches
with jointed hexagonal socket.
1
ADJUSTING THE SPRING
PRELOAD
Spring preload is adjusted by means of
screw 2. Turning clockwise will increase
the preload, while rotating counter- clock-
wise decreases the preload.
For standard calibration, refer to page
11.
2

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
