Beta EVO 2T User Manual

4
CHECKS AND MAINTENANCE
51
GB
Empty the fork leg and the cartridge, drain-
ing all the oil inside.
Reassemble the cartridge on the fork leg
tightening the fixing screw, then refill oil in
the cartridge.
Pour in the quantity of liquid indicated on
page 11.
Use the liquid indicated on page 18 in
the “Recommended lubricants and liquids”
table.
Reassemble the plug on the rod, tighten
the lock nut and, extending the fork leg.
OIL REPLACEMENT LEFT LEG
Unscrew upper plug 3.
Remove the spring and totally empty the oil.
Pour in the quantity of liquid indicated on
page 11.
Reassemble the spring and extend fork leg.
Apply and tighten cap 3.
3

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
