CLUTCH
EAS25061
CLUTCH
Removing the clutch cover
Order Job/Parts to remove Qty Remarks
Engine oil
1 Clutch cable 1
2 Oil filter element cover 1
3 Oil filter element 1
4 Clutch cover 1
5 Clutch cover gasket 1
6 Dowel pin 2
7 Oil seal 1
1
LS
New
7
New
New
LS
4
6
6
5
2
(6)
(4)
3
10 Nm (1.0 m
kgf, 7.2 ft
Ibf)
T
.R.
10 Nm (1.0 m
kgf, 7.2 ft
Ibf)
T
.R.
10 Nm (1.0 m
kgf, 7.2 ft
Ibf)
T
.R.
7 Nm (0.7 m
kgf, 5.1 ft
Ibf)
T
.R.
