Beta RR 125 LC - Page 49

CLUTCH
Removing the clutch
Order Job/Parts to remove Q’ty Remarks
1 Locknut 1
2 Clutch spring 4
3 Pressure plate 1
4 Short clutch push rod 1
5 Short clutch push rod holder 1
6Ball 1
7 Friction plate 1 1
8 Clutch plate 4
9 Friction plate 3 3 Green paint mark
10 Friction plate 2 1
11 Clutch damper spring 1
12 Clutch damper spring seat 1
13 Clutch boss nut 1
14 Lock washer 1
15 Clutch boss 1
16 Thrust washer 1
17 Clutch housing 1
New
E
E
10
(4)
(4)
8
9
9
8
8
9
8
7
E
6
4
5
3
2
1
11
12
13
14
15
16
17
18
8 Nm (0.8 m
•
kgf, 5.8 ft
•
Ibf)
T
.R.
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.R.
70 Nm (7.0 m
•
kgf, 50 ft
•
Ibf)
T
.R.
