Beta RR 125 LC - Page 67

CRANKCASE
5Spring 1
6 Engine oil strainer 1
7 Neutral switch 1
8 Circlip 2
9 Spacer 1
10 Right crankcase 1
11 Dowel pin 2
12 Left crankcase 1
Separating the crankcase
Order Job/Parts to remove Q’ty Remarks
8
9
8
New
New
New
New
1
3
2
4
5
6
7
11
11
10
12
LS
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
20 Nm (2.0 m
•
kgf, 14 ft
•
Ibf)
T
.R.
32 Nm (3.2 m
•
kgf, 23 ft
•
Ibf)
T
.R.
