Beta RR 125 LC - Crankcase Service; Separation and Component Removal

CRANKCASE
EAS25540
CRANKCASE
Separating the crankcase
Order Job/Parts to remove Q’ty Remarks
Engine
Cylinder head
Cylinder/Piston
Clutch housing
Oil pump assembly
Shift shaft
Starter motor
Balancer gears
Generator rotor
1 Timing chain guide (intake side) 1
2 Timing chain guard 1
3 Timing chain 1
4 Engine oil drain plug 1
8
9
8
New
New
New
New
1
3
2
4
5
6
7
11
11
10
12
LS
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
20 Nm (2.0 m
•
kgf, 14 ft
•
Ibf)
T
.R.
32 Nm (3.2 m
•
kgf, 23 ft
•
Ibf)
T
.R.
