Beta RR 125 LC - Page 76

TRANSMISSION
Disassembling the main axle
Order Job/Parts to remove Q’ty Remarks
1 2nd pinion gear 1
2 6th pinion gear 1
3 3rd/4th pinion gear 1
4 Circlip 1
5 Toothed washer 1
6 5th pinion gear 1
7 Main axle/1st pinion gear 1
E
E
E
2
1
4
5
3
6
7
New
