OPERATION
16
GB
1
MAIN PARTS
CLUTCH LEVER
Clutch lever 1 is fi tted to the left-hand side
of the handlebars.
LH SWITCH
The dip and service switch is located on
the left side of the handlebar and is com-
posed as follows:
1 - Horn button;
2 - Dip switch:
off;
high beam;
low beam;
3 - Shut-down : press the button until
the engine stops.
4 - Turn signal light switch: shifting lever
5 left or right activates the left or right
indicators. When released, the lever
returns to the central position. Press it
to turn the indicators off.
1
2
3
4
STARTER BUTTON
Starter button 1 is located on the right-hand
side of the handlebars and operate the
electric engine starter.
Do not press the button 1 while the engine
is running.
1
