3
ADJUSTMENTS
32
GB
Apply the handlebar.
Apply the top u-bolt.
Refi t the screws 6. Tighten to the torque
indicated.
6
25Nm
ADJUSTMENT OF THE
HANDLEBAR POSITION
The handlebar can be adjusted by rotating
it back and forth.
To adjust the handlebar loosen screws 1.
Position the handlebar according to re-
quirements.
Tighten to the torque indicated.
1
25Nm

Beta RR 350 Specifications

General

Bore x Stroke	88 mm x 57.4 mm
Ignition	DC-CDI
Lubrication	Wet sump
Transmission	6-speed
Clutch	Wet multi-disc
Front Brake	260 mm disc
Rear Brake	240 mm disc
Front Tire	90/90-21
Rear Tire	140/80-18
Seat Height	940 mm
Ground Clearance	320 mm
Dry Weight	107 kg
Rear Suspension	Sachs shock absorber
Fuel Capacity	9.5 liters
