4
CHECKS AND MAINTENANCE
49
GB
3
1
2
4
5
5
OIL FORK
The procedure for changing the oil in the
forks is provided only for information.
We recommend having the operation
performed by a BETAMOTOR authorized
workshop.
REMOVING LEGS
To replace, proceed as follows:
Position the vehicle on the central bike
stand.
Remove the cable gland U-bolt 1.
Remove the brake caliper 2.
Remove cap 3, loosen the screws 4, slide
the wheel pin out and remove the front
wheel.
Loosen shaft lock screws 5 and take off
the slider.
OIL REPLACEMENT
Place the legs vertically with cap 1 facing
upwards. Loosen the upper cap 1.
1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Beta RR 350 and is the answer not in the manual?

Beta RR 350 Specifications

General IconGeneral
Bore x Stroke88 mm x 57.4 mm
IgnitionDC-CDI
LubricationWet sump
Transmission6-speed
ClutchWet multi-disc
Front Brake260 mm disc
Rear Brake240 mm disc
Front Tire90/90-21
Rear Tire140/80-18
Seat Height940 mm
Ground Clearance320 mm
Dry Weight107 kg
Rear SuspensionSachs shock absorber
Fuel Capacity9.5 liters
