Beta RR 350 User Manual

4
CHECKS AND MAINTENANCE
51
GB
• Tighten the cap to the completely ex-
tended leg.
LEGS ASSEMBLY AND PARTS
Apply the legs to the vehicle and tighten
the screws to the torque indicated.
WARNING:
grease the screws before their application.
WARNING:
Tightening of the screws should be carried
out by adjusting the torque wrench to the
stability torque with repeated tightening
until stability torque has been achieved.
Apply wheel and wheel bolt.
Apply brake caliper, disc cover and fender.
Apply the cable gland U-bolt and tighten
the screws to the torque indicated.
Place the vehicle on the ground.
17Nm
12Nm
1,5Nm
35Nm

Beta RR 350 Specifications

General

Bore x Stroke	88 mm x 57.4 mm
Ignition	DC-CDI
Lubrication	Wet sump
Transmission	6-speed
Clutch	Wet multi-disc
Front Brake	260 mm disc
Rear Brake	240 mm disc
Front Tire	90/90-21
Rear Tire	140/80-18
Seat Height	940 mm
Ground Clearance	320 mm
Dry Weight	107 kg
Rear Suspension	Sachs shock absorber
Fuel Capacity	9.5 liters
