Beta RR 350 User Manual

4
CHECKS AND MAINTENANCE
38
GB
GEARBOX OIL
CHECK THE LEVEL
Hold the vehicle upright.
Position the drive on a fl at base ensuring
stability.
Remove the inspection cap 1.
The oil level must arrive to the lower edge
of check hole.
In contrary case restore the oil level through
cap 2.
Use the oil indicated on page 14 in
the “Recommended lubricants and liquids”
table.
REPLACEMENT
Always perform the replacement when
engine is hot:
- Position the drive on a fl at base ensuring
stability.
- Remove the engine casing by loosening
the screws shown in the fi gure.
- Place a container under the engine.
- Unscrew fi ller plug 2 and drain plug 3.
- Drain all the oil from the crankcase.
- Apply the cap 3 and tighten up to the
specifi ed torque.
Pour in the quantity of liquid indicated on
page 11.
Use the oil indicated on page 14 in
the “Recommended lubricants and liquids”
table.
3
1
2
2
20Nm

Beta RR 350 Specifications

General

Bore x Stroke	88 mm x 57.4 mm
Ignition	DC-CDI
Lubrication	Wet sump
Transmission	6-speed
Clutch	Wet multi-disc
Front Brake	260 mm disc
Rear Brake	240 mm disc
Front Tire	90/90-21
Rear Tire	140/80-18
Seat Height	940 mm
Ground Clearance	320 mm
Dry Weight	107 kg
Rear Suspension	Sachs shock absorber
Fuel Capacity	9.5 liters
