GENERAL INFORMATION
9
GB
Get off the male end wrenches and hexa-
gon socket 3. With these is possible to
unscrew the screw 4.
Pull the left cover of rear fender and unhook
two rubber band 5. Now the toolkit 6 is
accessible.
To take the tool kit, remove the saddle 1
(page 64). Pull the rear side panel 2
to remove it and unbind it by the strap of
the left mudguard.
4
1
2
3
6
5
5
