Binder KBF 720 - Replacing the Capillary Tubes

Repair work at the cooling system
10.4 Replacing the capillary tubes
When replacing the capillary tubes mind their tightness.
The capillary tubes should protrude by at least 40-50 mm / 1.57 x 1.97 in into the copper pipe.
40 -50 mm
A
B
C
Figure 57: Replacing the capillary tubes
A Copper pipe
B Soldering joint
C Capillary tube
116 Service Manual KBF (E5.2) 04-2015
