Repair work at the outer door
6.3.2 Replacing of components of the triangle instrument box
Spare parts:
Triangle instrument box complete (order no. 8008-0246)
or
Housing instrument box (order no. 6002-0180)
Switch mat 3-fold (order no. 6002-0196)
Switch mat 5-fold (order no. 6002-0184)
Filter pane of instrument box (order no. 6002-0160)
Controller display (order no. 5014-0059)
Necessary tools
Crosstip screwdriver, size 2
1. Dismantle the triangle instrument box (chap. 6.3.1).
2. Remove the controller display (F) (chap. 8.9).
3. Remove the component to be replaced:
- 3-fold switch mat (H)
- 5-fold switch mat (I)
- Filter pane (J)
4. Install the component by following steps 1 to 3 in reverse order.
52 Service Manual KBF (E5.2) 04-2015
