Binder KBF 720 - Replacing the Door Hinge Cover

Repair work at the outer door
6.2.2 Replacing the door hinge cover
Spare parts:
Door hinge cover (order no. 6002-0007)
Necessary tools:
Crosstip screwdriver, size 2
1. Remove the screws (B) of the door hinge covers (A).
2. Remove the door hinge cover.
3. Install the (new) door hinge cover by following steps 1 to 2 in reverse order.
A
A
Door hinge cover
B
Screw
Figure 9: Replacing the door hinge cover
Service Manual KBF (E5.2) 04-2015 45
