Spare parts
Name of spare part
order no.
Installation
Power cord with plug
8009-0483
chap. 8.2
Power cord with plug UL
8009-0436
Power cord with plug Switzerland
8012-0583
Power cord with plug England
8012-0220
Power connection board
4001-0269
Line filter (-1Z1)
5026-0016
chap. 8.3
Rocker switch 230 V AC/2 W (main switch and humidity switch)
5019-0010
chap. 8.4
Electric mounting plates
KBF 115, 720, electric mounting plate, complete
KBF 240, electric mounting plate, complete
8007-0349
8007-0348
chap. 8.6
Power relay (-5K2)
5011-0055
chap. 8.6
Solid state relay (-5K1)
5011-0042
Solid state relay (-4K1), (-4K2)
5011-0036
Solid state relay (-7K1), (-7K2)
5011-0045
Electric mounting plate option
Controller mTRON 4025 analog output (-12N1)
Controller mTRON 4015 relay (-11N1)
Through terminal green/yellow
Through terminal blue
Through terminal grey
Connector socket 12-poles
Connector socket 6-poles
Connector socket 9-poles
Connector socket 9-poles
Power contactor 230 V AC-2,2 kW (-5K4)
Relay (1 W / 10 A) 230 V AC + relay socket (-5K3)
5014-0074
5014-0075
5024-0022
5024-0021
5024-0020
5024-0153
5024-0157
5024-0173
5024-0185
5011-0008
5011-0010
chap. 8.7
Controller MB1 I/O Board (-3N1)
5014-0117
chap. 8.8.1
RS422 / Ethernet converter
5021-0021
chap. 8.11
Power supply unit
5020-0032
chap. 8.12
Humidification module, variant B 8009-0789 chap. 9.2
PU foam 1004-0009
chap. 7.8
chap. 7.9
chap. 7.11
Cooling system
Condenser complete.
KBF 115
KBF 115 UL
KBF 240
KBF 240 UL
KBF 720
KBF 720 UL
Condenser fan
KBF 115
KBF 115 UL
KBF 240
KBF 240 UL
KBF 720
KBF 720 UL
5013-0163
5013-0163
5013-0165
5013-0165
5013-0163
5013-0163
5013-0164
5013-0164
5013-0166
5013-0166
5013-0164
5013-0164
chap. 10.3
Service Manual KBF (E5.2) 04-2015 137
