MK / MKT (E5) 03/2019 page 42/158
Use the “Setpoints” menu to configure the operation lines.
“Setpoints” menu.
Select the field “Functions on/off”.
“Functions on/off” entry menu (example: MK
56).
Mark / unmark the checkbox to activate / deacti-
vate the desired function and press the Confirm
icon
Activated operation line: switching status “1” (On)
Deactivated operation line: switching status “0” (Off)
The operation lines count from right to left.
Example:
Activated operation line “Switching output 3” = 0000000000000
100
Deactivated operation line “Switching output 3” = 0000000000000
000
