144 | Appendix A: Specifications
General Specifications
Microplates
All models accommodate standard 6-, 12-, 24-, 48-, 96- and 384-well
microplates with 128 x 86 mm geometry up to 1.125" (28.575 mm) high, and
the Take3 and Take3 Trio Micro-Volume Plates.
Hardware & Environmental
Light Source: Absorbance:
Xenon flash light source, 10W maximum average
power
Fluorescence:
Tungsten halogen, 20W power
Dimensions: 16" D x 16" W x 10" H (40.6 cm x 40.6 cm x 25.4 cm)
Weight: 38 lb. (17 kg)
Environment: Operational temperature 18°C (64°F) to 40°C (104°F)
Humidity: 10% to 85% relative humidity (noncondensing)
Power Supply: 24-volt 90W external power supply compatible with
100-240 V~; +
10% @50-60 Hz
Power Consumption: 100 VA max, 130 VA max with injectors
Incubation:
Temperature control range from 4º over ambient
to 50ºC. Temperature variation ±0.5°C at 37°C, tested
with Innovative Instruments, Inc. temperature test
plate
Top and bottom incubation controlled via software-
adjustable gradient.
Plate Shaking:
Linear:
Orbital Slow:
Orbital Fast:
*Frequency is based on the amplitude selected
Amplitude: 1 mm to 6 mm in 1-mm steps
Frequency: 18 Hz to 6 Hz
Amplitude: 1 mm to 6 mm in 1 mm steps
Frequency: 10 Hz to 3 Hz
Amplitude: 1 mm to 6 mm in 1-mm steps
Frequency: 14 Hz to 5 Hz
BioTek Instruments, Inc.
